Specification
- Battery 48V 15Ah EVE lithium battery
- Range 30~45 Miles
- Electric Bike Class Class 2 (configurable to Class 3)
- Hub Motor 750W brushless geared motor, 1056W Peak
- Charging Time 4 ~ 5 Hours
- Total Payload Capacity 330lbs
- Recommended Rider Heights 5'1" ~ 6'7"
- Charger US standard 3.0 A smart charger, UL Certified
- Controller 48V / 22A 12-Tube
- Display Adjustable-Angle, Backlit, Grayscale 2.2'' LCD, IP67
- Frame Aluminium 6061
- Pedal
- Brake Calipers TEKTRO HD-E395
- Brake Levers Aluminium alloy comfort grip levers with motor cutoff switch
- Crank Set 48T, 170mm Aluminium Alloy, Double Sided Plastic Guard
- Fender Full coverage front and rear
- Freewheel Shimano TZ50-7 Freewheel
- Pedals Foldable, Wellgo ALuminum Alloy Platform with Reflector
- Seatpost Clamp Quick-Release type
- Front Suspension PARTNER Spring Suspension, 175mm Travel, Lockout and Preload Adjustment
- Rear Suspension Pre-adjusted suspension, GSX-200
- Brake Rotors TEKTRO 160mm front and rear
- Chain KMC chain with 122 chainlinks
- Derailleur7-Speed Shimano Tourney
- Gearing1 x 7 Speed
- HandlebarAluminum Alloy, 680mm Width, 31.8mm Bore
- KickstandHeavy-duty aluminum stand
- RimsAluminum Alloy, 20 inch, Double Wall
- SeatpostAluminum Alloy, 350mm*30.9mm Dia
- ShifterShimano SL-TX50-7R
- Tire20x4 CST BFT Puncture-Resistant
Geometry
- Total Length 72.8"
- B. Handlebar Height 42.9"-45.7“
- C. Wheelbase 44.5"
- D. Minimum Seat To Pedal 27.5“
- E. Maximum Extension 7.9"
- F. Chain Stay Length 16.9"
- H. Top Tube Length 25.2“
- I. Wheel Diameter 22.8“
- J. Head Tube Length 6.3“
- K. Handlebar Length 28.7“
- Folded Dimensions 35.4"/43.3"/29.1"
- Note: Seat-to-Ground Distance 32.6"-39.3"
